DIY Focal Reducer

I have built a DIY focal length reducer (focal reducer) by inserting a converging lens from an old telescope along the optical system of a Sky-Watcher Equinox 100ED . The telescope’s native focal length is 900 mm at f/9. With the DIY reducer, the focal length is reduced to 565 mm at f/5.65 (actual focal length as measured by SIRIL’s plate solver function). The lens used was the objective of a Vixen 80 mm f/11 achromat, reducing the native focal length of my telescope by 0.63x.

Focal reducers are optical elements (usually a convex lens or lens group) that converge light from a telescope’s objective. It shortens the focal length and in effect, produces a faster telescope (lower f/ratio) and widens the field of view (larger portion of the sky is seen or captured). Any decent quality converging lens should work as a focal reducer. It works opposite to a Barlow lens which increases the focal length by using a concave lens or diverging lens. Unlike dedicated focal reducers designed to maintain optimal image quality, DIY focal reducers may introduce aberration and must be considered when attempting this modification.

I had to shorten the optical tube by about 200 mm to reach focus, and then reattach the focuser. To see how long the telescope is prior to the modification, click here. The focuser’s draw tube was also shortened by 55 mm to prevent it from obstructing the light and stopping down the objective lens when moved inward. The telescope’s optical tube has an inner diameter of about 100 mm which has enough space to accommodate the lens cell of the Vixen 80 mm lens. Only the central 60 mm part of the reducer is used due to the presence of a light baffle in the telescope’s optical tube assembly.

To view posts on DIY projects and astronomical equipment, click here.
